高温合金锻件/GH1015圆棒锻件

高温合金锻件/GH1015圆棒锻件

单价 面议

更新时间:2018-11-12 09:12

401 人已联系

  • 商品详情
  • 单位名称: 上海同铸有色金属有限公司
  • 手机号码: 13681885956
  • 产品名称: 高温合金锻件/GH1015圆棒锻件
  • 材质型号: 上海同铸锻件厂
  • 供应地址: 上海市泗砖公路608号

GH1015是Fe-Ni-Cr基固溶强化型变形高温合金,使用温度在950℃以下,合金以加入铬、钨和钼等元素进行固溶强化。合金具有较高的塑性,中等的待久和蠕变强度、良好的抗冷热疲劳性能,以及良好的加工和焊接性能及组织稳定性,上海同铸主要产品有冷轧薄板、棒材、丝材和锻件。

合金已用于制造航空发动机燃烧室和加力筒体等板材结构件和其它高温部件。

合金700℃-900℃长期工作时有一定的时效硬化现象,使室温塑性下降;合金在700℃ 以上长期工作时有沿晶界氧化的倾向,可采用珐琅涂层进行有效的保护。在1000℃以上的高温抗氧化性能比同类用途的镍基合金稍差。该合金可作为GH2039、GH3030、GH3044、和GH3536合金的代用料。

GH1015高温合金化学成分

合金

C

Cr

Ni

W

Mo

Fe

Nb

B

Ce

Si

Mn

P

S

Cu

GH1015

≤0.08

19-22

34-39

4.8-5.8

2.5-3.2

1.10-1.60

≤0.01

≤0.05

≤0.06

≤1.5

0.02

0.015

0.25

热处理制度:冷轧薄板、丝材、焊接组合件,1130℃-1170℃空冷。

热轧和锻制棒材、锻件、模锻件,1140℃-1170℃空冷。

主营镍合金牌号有:

1.变形高温合金:GH1015, GH1016, GH1035, GH1040, GH1131, GH1140, GH2018, GH2036, GH2038, GH2130, GH2132, GH2135, GH2136, GH2302, GH3030, GH3039, GH3044, GH3128, GH4033, GH4037, GH4043, GH4049, GH4133, GH4169.
2.哈氏合金:

Hastelloy B, Hastelloy B-2,HastelloyB-3,Hastelloy C,Hastelloy C-4,Hastelloy C-22,    Hastelloy C-276, Hastelloy C-2000, Hastelloy G-30, Hastelloy G-35, Hastelloy N,

Hastelloy S, Hastelloy W, Hastelloy X.                         3.英科耐尔合金:Inconel 600, Inconel 601, Inconel 601GC, Inconel 617, Inconel 622, Inconel 625, Inconel 625LCF, Inconel 671, Inconel 672, Inconel 686, Inconel 690, Inconel 706, Inconel 718, Inconel 718SPF, Inconel 725, Inconel X-750, Inconel 751, Inconel 754,Inconel 758, Inconel 783.
4.因科洛伊合金:Incoloy DS, Incoloy 800, Incoloy 800H, Incoloy 802, Incoloy 803, Incoloy 804, Incoloy 825, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy MA956, Incoloy A-286, Incoloy 25-6Mo.
5.蒙乃尔合金: Monel 400, Monel R-405, Monel 450, Monel K-500, Monel S.
6.特殊不锈钢:904L, 2205, 2507, Carpenter 20Cb3, 309S, 310S, 310Si, 316LMod, 316Ti, 317LMod, 347, 347H, 329, S21800, 254SMO, AL-6XN, 20Mo-6, 17-4PH, 17-7PH, 15-5PH, 410, 420, 430.
7.耐蚀合金:NS111, NS112, NS142, NS143, NS312, NS313, NS315, NS321, NS322, NS333, NS334, NS335, NS336.
